The BASE series combines a servomotor and linear mechanism in a particularly space-saving design. It is idealfor centrally controlled applications where the focus is on compact design, free positioning and easy integration. Thanks to a range of configurations, it offers a high-performance solution for a wide variety of tasks – from positioning to dynamic movement.
The order number is determinedindividually based on the configuration of your requirements. Please feel freeto contact us – we will check the feasibility in advance and calculate the bestsolution for you.
Request
An integrated servo motor with position sensors enables movement profiles ranging from simple to complex without the need for compressed air.
Energy savings of more than 90 percent compared to pneumatic systems.
Compatible with any motion controllers and bus systems.
Hybrid connection via a rotatable circular connector with a quick-lock system.
To IP65 for wet applications and a wide range of industrial environments.
High-resolution encoder system withvarious interfaces and resolutions.
See for yourself: SMELA offers you a unique opportunity to test our innovative actuators in your application for 30 days, free of charge and with no obligation—as part of an evaluation order.
Thanks to our international partner network, we are always available for our customers in Europe and beyond. Our sales partners provide you with technical advice, a local point of contact, and comprehensive application expertise. Together, we ensure that our electromechanical actuators are optimally integrated into your processes – from your initial inquiry to successful commissioning.
Would you like to learn more about liteECO® actuators? Here you’ll find answers to the most frequently asked questions about performance, dynamics, integration, and applications. We’d be happy to provide personalized advice for your specific needs.
liteECO® actuators are ideal wherever fast and precise linear movements are required – for example, in production lines, machine tools, and packaging and logistics systems. They are used for positioning, securing, adjusting, or locking components in place. Some applications are listed on the product pages.
Depending on the model, the wear parts of liteECO® actuators have service lives ranging from 1 million to 50 million cycles. Typically, the nut in the plunger — which is made of high-performance plastic or bronze, depending on the variant — wears out first.
Wear can be detected early through predictive maintenance functions and, in many cases, compensated for by the control system. Thanks to our refurbishment concept, worn nuts can be replaced quickly, easily, and cost-effectively by replacing the plunger.
This ensures that the actuator remains fully operational and economically viable over multiple life cycles.
Yes. Depending on the motion controller, position, speed, acceleration, and custom motion sequences can be flexibly configured. Stand-alone applications without a higher-level PLC, as well as teach-in functions for easy position setup, are also possible.
The liteECO® size 50 has a flange dimension (width) of 50 mm, with a hole spacing of 42 × 42 mm and a 20 mm centering ring. Depending on the model, there are various flange mounting options (from the front, from the rear, or as a through-hole). Please refer to the data sheets on the product pages for the latest technical specifications.
